Square 19'' Open Frame Touch Screen Monitor 1280×1024 IPS

Square 19'' Open Frame Touch Screen Monitor 1280×1024 IPS

Product Details:

Place of Origin: China
Brand Name: YONGS

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Payment Terms: T/T, Western Union
Get Best Price Contact Now

Detail Information

Use: Industrial Touchscreen Interface: USB(RJ45)
Response Time: 5ms Brightness: 400cd/m
Contrast Ratio: 1000:1 Interface Type: DVI, Support HDMI Input, VGA, Usb
Toucshcreen: Resistive /capacitive Touchscreen Option Language: Multi-language
Power Supply: DC 12V-DC24V Installation: Embedded/VESA Holes/Wall-mounted/Desktop
High Light:

19'' open frame touch screen monitor


1024 IPS open frame touch screen monitor


1280 IPS monitor touch screen open frame

Product Description

Square screen 19 inch industrial grade lcd monitor



Industrial grade LED panel
Black and white Metal casing option
Resistive /capacitive touchscreen option
VGA/HDMI/DVI/RJ45 interface
Can work in harsh environments
Support DC12V-DC24V wide voltage input
Suport work temperatures -20° to 70°
Embedded/panel mount/card buckle/VESA holes installation
Effective prevention of external magnetic interference
Multi-language,Support Windows/Linux OS
Anti-surge design, the voltage rises 280V instantly
GB2423 standard Anti-vibration design

Be used in transportation,industrial, offshore and other working environments


Product details :


LCD panel Panel size 19inch
Resolution 1280×1024
Aspect ratio 4:3
Brightness 400cd/m2
Contrast ratio 1000:1
Display color 16.7M
View angle H170; V160
Pixel pitch 0.264mm
Response time 5ms
Backlight LED backlight
Life >50000h
Touchscreen 10points Capacitive touchscreen ( 5-wire resistive touchscreen option)
Touch number >50 million
Touch way Pressure sensing
Touchscreen interface RJ45 interface
Other Power supply DC12-24V/4A, AC100-240V/50-60Hz,
Power Consumption <48W
Work temperature -20℃-70℃
Environment humidity 10%-90%(No condensation)
Language Multi-language
Dimension 428.1×354.5×55.5mm
Casing Whole aluminum alloy casing
Interface 1xVGA,1xDVI, 1xHDMI,1xAudio I/O,1xRJ45(for touchscreen),1xDC power
Installation Embedded/Panel mount/VESA holes/Wall-mounted/desktop
Accessories Manual,Adapter, Power cord,VGA cable,Buckles,Embedded irons



Why Choose Us :


According to customers' various requests,

we can match all accessories which inclusive of driver board,

touch-screen, LED backlight & LVDS cables. TFT LCD,

LCD panel, LCD display,LCD screen, LCD monitor,

LCD module from 2.2 inch to 88 inch.

Quality promised, 100% original,fast delivery,

also enjoy one year guarantee !


Shipping and Package :

Square 19'' Open Frame Touch Screen Monitor 1280×1024 IPS 0


1)All of our product will be testing before shipping . So you can be assured the quality of our products


2) All Panels are packed with new and firm carton, capable of long distance transportation.




4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.




Q: Why choose YONGS?

A: 1. Professional Industrial open frame monitor manufacture for years with great experience .

2. Own factory , you could share direct factory price .

3. Quality guaranteed by our QC.

4. Low price , but in high quality .

5. OEM/ODM supported



Q: What's the time of delivery ?

A: It's subject to your order quantity and our production schedule . Usually , 3-5 working days for sample order ,

7-15 working days for mass production after receipt of payments .



Q: What paying methods do you accept ?

A: T/T and WestUion .



Q: How is your warranty policy for goods ?

A: We focous on our after-sale service , and all our products share 12 months' warranty .
