LCD Screen Display Panel

PT430CS03-3 43.0 inch 1920*1080 120 pins LCD Display

All Category

Floor Standing Digital Signage

Stretched Bar LCD Display

chance

info@yongs-hk.com

86-18575563918

Contact Now

PT430CS03-3 43.0 inch 1920*1080 120 pins LCD Display

Brand Name:	YONGS
Model Number:	AC-C1134-7.0
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Diagonal Size:

7.0-inch

Structures:

Cover Glass+ITO Glass

Surface Hardness:

>6H

Outline Size:

193.0*132.0mm

View Area:

152.4*91.44mm

Operating Temperature:

-20℃~70℃

Interface Mode:

USB/IIC/RS232

Supply Ability:

100000 Unit/Units per Month

Product Description

PT430CS03-3 43.0 inch 1920*1080 120 pins LCD Display

PT430CS03-3 LCD Panel Product details :

Brand	HKC
Model P/N	PT430CS03-3
Diagonal Size	43"
Panel Type	a-Si TFT-LCD, CELL
Resolution	1920(RGB)×1080, FHD 51PPI
Pixel Format	RGB Vertical Stripe
Active Area	940.896(W)×529.254(H) mm
Bezel Opening	-
Outline(mm)	950.896 × 541.75× 1.4 (H×V×D)
Treatment	Antiglare, Hard coating (3H)
Luminance	0 cd/m²
Contrast Ratio	1200 : 1 (Typ.) (TM)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Response	8 (Typ.)(G to G) ms
Good View at	Symmetry
Work Mode	HIS, Normally Black, Transmissive
Glass Thickness	0.50+0.50 mm
Transmissivity	6.3% (Typ.)(with Polarizer)
Color Depth	16.7M 72%NTSC
Backlight	No B/L
Mass	1.60Kgs
Used for	TV Sets
Refresh Rate	60Hz
Touchscreen	Without
Driver IC list	Built-inCOG6 source chips
Signal Type	Mini LVDS, 120 pins Connector
Max. Ratings	Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
PT430CS03-3 43.0 inch 1920*1080 120 pins LCD Display

PT430CS03-3 LCD Panel Note :

Model Verification:

Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.

Comprehensive Testing:

We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.

PT430CS03-3 LCD Panel Shipping and Package :

PT430CS03-3 43.0 inch 1920*1080 120 pins LCD Display 0

PT430CS03-3 LCD Panel Shipping Guidelines:

Address Confirmation:

It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.

Shipment Timeline:

Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.

PT430CS03-3 LCD Panel ESTIMATED DELIVERY TIME :

Standard Shipping:

The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.

Expedited Shipping:

For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.

PT430CS03-3 LCD Panel FAQ :

Q: When would you ship,IF I order PT430CS03-3 now?

A: The order are shipped within 1-2 working days after received the payment.

Q: Do you accept the sample order?

A: Yes , sample order is welcome.

Q: How to order if I don't know the lcd panel number ?

A: You can offer 2-3 photos (back-side and front-side) for your lcd panel ,So that we can check the panel to you.

Q: Can you declared low value for my order when shipping?

A: Yes, We can do it for you if you need.
