LCD Screen Display Panel

original 23.6 inch PT236AT02-1 1366*768 LCD Panel screen

All Category

Floor Standing Digital Signage

Stretched Bar LCD Display

chance

info@yongs-hk.com

86-18575563918

Contact Now

original 23.6 inch PT236AT02-1 1366*768 LCD Panel screen

Brand Name:	YONGS
Model Number:	JSY-69.3I1
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

JSY-69.3I1

Diagonal Size:

69.3 Inches

Dimensions:

1688.5 * 657 * 45.5mm (length * Width * Thickness)

Display Size:

1649.5 * 618mm

Display Resolution:

3840 * 1440

Brightness:

Adjustable From 300~500cd/㎡

Perspective Range:

89/89/89/89 (U/D/L/R)

Package Size:

1848*165*840(length * Width * Height)mm

Supply Ability:

100000 Unit/Units per Month

Product Description

original 23.6 inch PT236AT02-1 1366*768 LCD Panel screen

PT236AT02-1 LCD Panel Product details :

Brand	HKC
Model P/N	PT236AT02-1
Diagonal Size	23.6"
Panel Type	a-Si TFT-LCD, CELL, FOB
Resolution	1366(RGB)×768, WXGA 66PPI
Pixel Format	RGB Vertical Stripe
Active Area	521.471(W)×293.184(H) mm
Bezel Opening	-
Outline Dim.	535.471(H)×306.404(V)×1.37(D) mm
Treatment	Antiglare (Haze 3%), Hard coating (3H)
Luminance	0 cd/m²
Contrast Ratio	3000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	9.5 (Typ.)(G to G)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Operating Mode	FSA, Normally Black, Transmissive
Plate Thickness	0.50+0.50 mm
Transmittance	5.8% (Typ.)(with Polarizer)
Support Color	16.7M 70%NTSC
Light Source	No B/L
Weight	500g (Typ.)
Designed For	TV Sets
Frame Rate	60Hz
Touch Panel	Without
D-IC Detail	COF Built-in 2 source + 2 gate chips
Interface Type	LVDS (1 ch, 8-bit), 30 pinsConnector
Power Supply	12.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
original 23.6 inch PT236AT02-1 1366*768 LCD Panel screen

PT236AT02-1 LCD Panel Note :

Model Verification:

Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.

Comprehensive Testing:

We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.

PT236AT02-1 LCD Panel Shipping and Package :

original 23.6 inch PT236AT02-1 1366*768 LCD Panel screen 0

PT236AT02-1 LCD Panel Shipping Guidelines:

Address Confirmation:

It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.

Shipment Timeline:

Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.

PT236AT02-1 LCD Panel ESTIMATED DELIVERY TIME :

Standard Shipping:

The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.

Expedited Shipping:

For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.

PT236AT02-1 LCD Panel FAQ :

Q: What happen if the lcd panel PT236AT02-1 I received can't work ?

A: All the goods will be tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.

Q: How to do if I can't find the screen that I require in your listings?

A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .

Q: Why big order delivery time are long?

A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!

Q:Can you declared low value for my order when shipping?

A:Yes, We can do it for you if you need.
