Stretching strip 28.6 inch LCD display screen advertising display monitor LCD strip monitor
  • name
  • name
  • name
  • name
  • name

Stretching strip 28.6 inch LCD display screen advertising display monitor LCD strip monitor

Brand Name: YONGS
Model Number: JSY-286X1
MOQ: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Payment Terms: T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Model Name:
JSY-286X1
Diagonal Size:
28.6 Inches
Input Power Supply:
AC 220V
Resolution:
1920 * 540
Weight:
Net Weight: 6KG Gross Weight: 8KG
Display Size:
698.4 * 196.43mm
Dimensions:
748 * 245.5 * 45.8mm (length * Width * Thickness)
Brightness:
Adjustable From 200~500cd/㎡
Package Size:
820*110*340(length * Width * Height)mm
Perspective Range:
89/89/89/89 (U/D/L/R)
Supply Ability:
100000 Unit/Units per Month
Highlight:

37.0 inch LCD Display Panel

,

72%NTSC LCD Display Panel

,

LC370WUD-SBT1 LCD Display Panel

Product Description
Stretching Strip 28.6 Inch LCD Display Screen
Model: JSY-286X1
Key Specifications
Attribute Value
Diagonal Size 28.6 inches
Resolution 1920 × 540
Display Size 698.4 × 196.43mm
Dimensions 748 × 245.5 × 45.8mm
Brightness Adjustable 200-500cd/㎡
Viewing Angle 89°/89°/89°/89° (U/D/L/R)
Power Supply AC 220V
Weight Net: 6KG, Gross: 8KG
Technical Features
  • T972 quad-core A55 CPU (1.9GHz) running Android 9.0
  • 2GB DDR3 RAM + 8GB FLASH storage (expandable)
  • Supports 1080P high-definition video decoding
  • Multiple interfaces: SD card slot, RJ45, HDMI, USB (x2)
  • Multi-language OSD support including Chinese/English
  • Supports wide range of media formats (video/audio/image)
  • 2×5W speakers (8Ω)
Product Image
Stretching strip 28.6 inch LCD display screen advertising display monitor LCD strip monitor 0
Applications

This ultra-wide bar-shaped LCD screen is ideal for narrow space installations in various industries:

  • Retail: Shelf advertising, price tags, promotions
  • Transportation: Subways, buses, airports for route/announcement displays
  • Hospitality: Electronic menu boards, storefront advertising
  • Public spaces: Government halls, banks, hospitals for information displays
  • Industrial: Equipment status display interfaces
Shipping & Packaging
Stretching strip 28.6 inch LCD display screen advertising display monitor LCD strip monitor 1

Packaged in protective materials with dimensions: 820×110×340mm (L×W×H)

Frequently Asked Questions
Q: How is the product delivered?

A: Small orders via express (UPS/DHL/FEDEX), bulk orders by sea/air.

Q: Do you accept small orders?

A: Yes, sample orders and drop shipping available.

Q: What are your payment terms?

A: 100% prepayment for small orders, 30% deposit for bulk orders.

Q: Are products tested before delivery?

A: Yes, 100% tested 5 times before shipping.

Quality Assurance

All products undergo rigorous testing and come with warranty coverage. We offer competitive pricing for bulk orders and guarantee prompt delivery with secure packaging.
