LC230W02-A5K4 23.0 inch 1366*768 LCD Panel Display
Product Details:
Place of Origin: | China |
Brand Name: | LG |
Model Number: | LC230W02-A5K4 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | LC230W02-A5K4 | Diagonal Size: | 23.0" |
---|---|---|---|
Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1366(RGB)×768, WXGA 68PPI |
Pixel Format: | RGB Vertical Stripe | Active Area: | 508.152(W)×285.696(H) Mm |
Color Depth: | 16.7M 72% NTSC | Light Source: | EEFL [15 Pcs], 50K Hours, With Inverter |
Used For: | TV Sets | Refresh Rate: | 60Hz |
Product Description
LC230W02-A5K4 23.0 inch 1366*768 LCD Panel Display
LC230W02-A5K4 LCD Panel Product details :
Brand | LG |
Model P/N | LC230W02-A5K4 |
Diagonal Size | 23.0" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 1366(RGB)×768, WXGA 68PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 508.152(W)×285.696(H) mm |
Bezel Opening | 513.0(W)×290.6(H) mm |
Outline Dim. | 559.8(H)×333.8(V)×46(D) mm |
Treatment | Antiglare, Hard coating (3H) |
Luminance | 500 cd/m² (Typ.) |
Contrast Ratio | 550:1 (Typ.) (TM) |
View Direction | Symmetry |
Response Time | 7/9 (Typ.)(Tr/Td) |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
Operating Mode | S-IPS, Normally Black, Transmissive |
Support Color | 16.7M 72%NTSC |
Light Source | EEFL [15 pcs], 50K hours, With Inverter |
Weight | 4.20Kgs (Typ.) |
Designed For | TV Sets |
Frame Rate | 60Hz |
Touch Panel | Without |
Interface Type | LVDS (1 ch, 8-bit), 30 pinsConnector |
Power Supply | 12.0V (Typ.) |
Environment | Operating Temperature: 0 ~ 40 °C; Storage Temperature: -20 ~ 50 °C |
