AUO a-Si TFT-LCD 480×234 A024CN02 VL LCD Screen Display
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | A024CN02 VL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | A024CN02 VL | Screen Size: | 2.4 Inch |
|---|---|---|---|
| Resolution: | 480×234 120PPI | Display Area: | 48 × 35.685 Mm (H×V) |
| Physical Dimension: | 55.2 × 47.55 Mm (H×V×D) | Visual Size: | 50.6 × 38.28 Mm (H×V) |
| Luminance: | 250 Cd/m² (Typ.) | Contrast: | 250:1 (Typ.) (transmission) |
Product Description
AUO a-Si TFT-LCD 480×234 A024CN02 VL LCD Screen Display
Product details :
| AUO LCD SCREEN A024CN02 VL | |
| manufacturer | AUO |
| model | A024CN02 VL |
| Diagonal size | 2.4inch |
| Types of | a-Si TFT-LCD, LCD module |
| Resolution | 480×234 120PPI |
| Pixel | RGB triangle |
| Display area | 48 × 35.685 mm (H×V) |
| physical | 55.2 × 47.55 mm (H×V×D) |
| Open area | 50.6 × 38.28 mm (H×V) |
| Surface | Hard coating |
| Display | 250 cd/m² (Typ.) |
| Contrast | 250:1 (Typ.) (transmission) |
| Recommended | 6 o'clock |
| Response time | 20/30 (Typ.)(Tr/Td) ms |
| Viewing angle | 45/45/15/35 (Typ.)(CR≥10) |
| Display mode | TN, normally white display, transmissive |
| Support color | 16.7M |
| type of light | WLED [1 pcs], no driver |
| Application | camera |
| Touch | No touch |
| Interface Typ | Serial RGB (8-bit) + SPI, CCIR601/656, FPC, 40 pins |
| Voltage supply | 3.3/3.3/3.3V (Typ.)(VCC/AVDD/PVDD) |
| Maximum | Working: 0 ~ 60 °C; Storage: -25 ~ 70 ° |
| AUO a-Si TFT-LCD 480×234 A024CN02 VL LCD Screen Display | |
AUO A024CN02 VL Mechanical Details
| Pixel Features : | Resolution | 480×234 | Dot Pitch(mm) | 0.1000×0.1525 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Delta | Pixel Pitch(mm) | - [120PPI] | |
| Mechanical Size : | Active Area(mm) | 48(H) × 35.685(V) | Bezel Area(mm) | 50.60(H) × 38.28(V) |
| Outline Dim.(mm) | 55.2(H) × 47.55(V) | Depth(mm) | 3.09 | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | TBD | Treatment | Hard coating |
