Brand new 8.9 slim 1280x768 LD089WX1-SL03 LVDS TFT LCD Screen Display Panel
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | LG Display |
| Model Number: | LD089WX1-SL03 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | LG Display | Model Name: | LD089WX1-SL03 |
|---|---|---|---|
| Screen Size: | 8.9 Inch | Resolution: | 1280(RGB)×768, WXGA, 167PPI |
| Display Size: | 193.92(W)×116.352(H) Mm | Physical Dimension: | 207(width)×130.4(height) ×3.2(thickness) Mm |
| Bezel Area: | 196.92(W)×119.35(H) Mm | Brightness: | 370 Cd/m² (Typ.) |
| Contrast: | 800:1 (Typ.) (TM) | Apply To: | Tablet |
Product Description
Brand new 8.9 slim 1280x768 LD089WX1-SL03 LVDS TFT LCD Screen Display Panel
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| LG Display LCD SCREEN LD089WX1-SL03 | |
| manufacturer | LG Display |
| Model Name | LD089WX1-SL03 |
| screen size | 8.9 inch |
| Screen type | a-Si TFT-LCD, LCD module |
| Resolution | 1280(RGB)×768, WXGA, 167PPI |
| Pixel configuration | RGB vertical bar |
| Display size | 193.92(W)×116.352(H) mm |
| physical dimension | 207(width)×130.4(height) ×3.2(thickness) mm |
| Visual size | 196.92(W)×119.35(H) mm |
| surface treatment | Mirror (Haze 0%) |
| Brightness | 370 cd/m² (Typ.) |
| Contrast | 800:1 (Typ.) (TM) |
| Best angle | Full view |
| Optical mode | S-IPS, normally black display, transmissive |
| Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| Responding time | 35 (Typ.)(Tr+Td) ms |
| Number of color | 16.7M, 50% NTSC |
| Backlight type | 7S4P WLED, without driver |
| Panel weight | 137/150g (Typ./Max.) |
| Apply to | tablet |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (1 ch, 8-bit), 30 pins, connector |
| Supply voltage | 3.3V (Typ.) |
| Maximum rating | Working: 0 ~ 50 °C; Storage: -20 ~ 60 °C |
| Brand new 8.9 slim 1280x768 LD089WX1-SL03 LVDS TFT LCD Screen Display Panel | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ :
Q: How can I trace my order of LD089WX1-SL03 ?
A: we will give you tracking number then you can trace your order from website.
Q: Can you give me a discount if I need a large quantity of LD089WX1-SL03 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How to make payment of LD089WX1-SL03 ?
A: We accept T/T , Paypal , western union .
Q: Can you give me a discount if I need a large quantity of LD089WX1-SL03 ?
A: Of course!If you make a large order, we will give you a discount.
We are one of the professional and experienced suppliers of Brand new 8.9 slim 1280x768 LD089WX1-SL03 LVDS TFT LCD Screen Display Panel, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.
